T500-A
All-in-One ITS Sensing Unit
- 4 TOPS, two 8-megapixel lenses, 1/1.8″ CMOS image sensor, F1.6 wide aperture
- Automatic calibration of radar and video data fusion
- Automatic correction of the device installation position offset
- Works in the 80 GHz frequency band
- Supports multi-lane detection (camera: up to 6 lanes)
- Built-in Illuminators
Delivery & Return
We want you to be happy with your purchase and we apologize if it is not. For whatever reason that you are not satisfied, we would be most happy to provide exchanges and returns for all items purchased from us if the following conditions are met.
Rules
For delivery and returns information, please review our Return & Refund Policy or contact our team before ordering. Eligibility and time limits depend on the product condition, order type, manufacturer terms, and the terms agreed in your quotation.
Interpretation and Definitions
For delivery and returns information, please review our Return & Refund Policy or contact our team before ordering. Eligibility and time limits depend on the product condition, order type, manufacturer terms, and the terms agreed in your quotation.
Accessories from hundreds of brands
Technical Spec
| Computing power | 4 TOPS |
| Lens type | Two prime lenses |
| Focal length | Short-focus lens: 12 mm; Long-focus lens: 25 mm |
| Resolution | 8MP 3840(H)*2160(V) |
| Video compression format | H.264 and H.265 |
| Protocol | GB/T 28181, GA/T 1400, and GA/T 920 |
| Web browser | Google Chrome and Firefox |
| Antenna beamwidth | Near beam (0–100 m): 90 x 20° (3 dB); medium beam (100–250 m): 24 x 10° (3 dB); far beam (250–500 m): 9 x 8° (3 dB) |
| Operating frequency | 80 GHz (79~81GHz) |
| Power supply | 24 V AC (±10%); DC24V |
| Power consumption | ≤ 30 W |
| Operating temperature | –30°C to +70°C |
| Body dimensions (H x W x D) | 288.1 mm x 302.5 mm x 233 mm |
| Network port | One RJ45 10M/100M/1000M adaptive Ethernet port |
| Built-in Illuminators | 8 LED Lights |
| Installation method | Beam-mounted |
| Waterproof rating | IP66 |
| Weight | Maximum: 7 kg |
| Covered lanes | camera: up to 6 lanes; radar: 10 lanes |
| Detection distance | Radar and video fusion data: 200m |
| Speed measurement range | –200 km/h to +200 km/h |
| Velocity resolution | 0.6 km/h |
| Speed Precision | 0.3 km/h |
| Real-time data collection | Queue length, vehicle flow statistics, time occupancy |
| Management | Supports multiple functions such as automatic time calibration (through NTP server), auto reboot, running status monitoring, and embedded logs |
| Calibration | Automatic calibration based on data collected by the radar detector and camera |
