SSJ1JBPA(17/-38 LC)

Model:SSJ1JBPA(17/-38 LC) – Huawei OSN 9500 Amplifier Board
Detail:Pre-amplifier Board(-38dBm~-10dBm,22dB,-6dBm~+3dBm,17dBm,LC)
Guaranteed safe & secure checkout
Description
Reviews (0)
Q & A

Warranty: supplied with the Green Code 1-year standard hardware repair warranty. Any manufacturer warranty terms shown in the specifications below are the manufacturer’s own.

SSJ1JBPA(17/-38 LC) is a Huawei optical amplifier, configured as a pre-amplifier for the OSN 9500. An optical amplifier lifts the power of every wavelength on the fibre at once, without converting anything to electrical form and back, which is the single development that made long-haul DWDM practical.

A pre-amplifier sits at the receive end, lifting a weak arriving signal to a level the receiver can work with. Its critical specification is not gain but noise: it amplifies the noise along with the signal, so a pre-amplifier with a poor noise figure sets a floor on the performance of the whole span that no amount of downstream gain can recover.

Its input range is -38 to -10 dBm. That range matters as much as the gain figure: below it the amplifier has too little to work with and the output is dominated by noise, and above it the amplifier saturates, so the gain falls and the output no longer tracks the input. Keeping the input inside the window is what the span budget and any attenuators in the path are there to achieve.

Gain is 22 dB with an output of 17 dBm. Those two figures together are what tell you where this amplifier can sit: the output sets how much span it can drive, and the gain sets how weak an input it can lift to that level. On a span that comes in stronger than expected the amplifier will deliver its rated output rather than its rated gain, which is saturation behaving as designed.

Amplifiers are also where optical safety stops being theoretical. The powers here are high enough to cause eye injury and to burn a dirty connector, and a contaminated or poorly mated connector at an amplifier output can be destroyed in seconds. Never look into a fibre or a port, treat every port as live, and clean and inspect before mating. It is also worth knowing that amplifiers can mask a developing problem: as a span degrades, the amplifier compensates until it runs out of range and then the link fails apparently without warning, which is why trending the input power is more useful than watching for alarms.

Send us the span loss, the number of channels and the launch and receive levels at each end and we will tell you whether this amplifier fits the design, where it belongs in the chain, and whether the span needs one amplifier or a chain of them.

Green Code Technologies supplies Huawei optical transport equipment, including amplification, filtering and compensation. We are a supplier of Huawei alongside HPE, Dell, Cisco, Samsung and Netgear, and we would rather confirm a part against Huawei’s own documentation than sell you the wrong one, which on OSN 9500 equipment is worth doing. Send us the span, the fibre type, the channel plan and the levels at each end and we will come back with a straight answer.

SSJ1JBPA(17/-38 LC) Specification

Pre-amplifier Board(-38dBm~-10dBm,22dB,-6dBm~+3dBm,17dBm,LC)
