MS220-8P
| Model: | MS220-8P – MS220-8 Series Access Switches |
| Detail: | 8-port PoE gigabit switch with 2 SFP interfaces |
Delivery & Return
We want you to be happy with your purchase and we apologize if it is not. For whatever reason that you are not satisfied, we would be most happy to provide exchanges and returns for all items purchased from us if the following conditions are met.
Rules
For delivery and returns information, please review our Return & Refund Policy or contact our team before ordering. Eligibility and time limits depend on the product condition, order type, manufacturer terms, and the terms agreed in your quotation.
Interpretation and Definitions
For delivery and returns information, please review our Return & Refund Policy or contact our team before ordering. Eligibility and time limits depend on the product condition, order type, manufacturer terms, and the terms agreed in your quotation.
Accessories from hundreds of brands
MS220-8P Specification | |
Interfaces | 8 × 10/100/1000BASE-T Ethernet (RJ45) with auto-MDIX crossover |
48V DC 802.3af/802.3at Power-over-Ethernet (PoE/PoE+) on the MS220-8P model, available on all ports (maximum of 30W per port for PoE+) | |
2 × SFP Gigabit Ethernet interfaces for uplink | |
Auto negotiation and crossover detection | |
Ethernet switching capabilities | 802.1p Quality of Service prioritization |
802.1Q VLAN tagging with 4,095 addressable tags | |
802.1D Spanning Tree Protocol (RSTP, STP) | |
802.1ab Link Layer Discovery Protocol (LLDP) | |
802.3ad link aggregation with up to 8 ports per aggregate | |
Broadcast storm control | |
IGMP snooping for multicast filtering | |
MAC forwarding table entries: 8,000 | |
Security | Integrated two-factor authentication |
Role-based administration | |
Corporate wide password policy enforcement | |
IEEE 802.1X port-based security | |
Performance | Non-blocking fabric |
20 Gbps non-blocking switching capacity | |
2.5 microsecond latency | |
Power over Ethernet | 802.3af (PoE) 15.4 W per port and 802.3at (PoE+) 30 W per port |
Maximum PoE output: 124 W | |
PoE available on all ports simultaneously | |
Pre-standard PoE: supports pre-standard PoE devices | |
Management | Managed via the cloud using the Meraki dashboard |
Integrated with Meraki wireless, routing, and firewall management | |
No-touch remote deployment (no staging needed) | |
Detailed historical per-port and per-client usage statistics | |
DHCP and hostname fingerprinting | |
SNMP v2c | |
Seamless over-the-web firmware upgrades | |
Remote diagnostics | Email and text alerts |
Live remote packet capture | |
Aggregated event logs with instant search | |
Scalable stacking | Unified configuration and monitoring of all switches |
Virtually stack thousands of switch ports in a single logical stack for unified management, monitoring, and configuration | |
Power | Power input: 100-240 VAC, 47-63 Hz |
power consumption: 13-159 W max | |
Environment | Operating temperature: 32°F to 104°F (0°C to 40°C) |
Humidity: 5 to 95% non-condensing | |
Silent operation for office environments | |
Surface (wall/desk) mountable with integrated brackets | |
Warranty | Lifetime hardware warranty with advanced replacement included |
Physical dimensions | Weight: 3.0 lbs (1.3 kg) |
9.1″(w) x 8.7″ (l) x 1.8″ (h) (23.0 x 22.0 x 4.4 cm) | |
