S5710-28C-EI

S5710-28C-EI Specification

Fixed port

24×10/100/

1000Base-T

Extended slot

S5700C Provide two extended slots, one for an uplink subcard and the other for a stack card.

S5710C Provide two extended slots for uplink subcards.

MAC address table

IEEE 802.1d compliance

32K MAC

MAC address learning and aging

Static, dynamic, and blackhole MAC address entries

Packet filtering based on source MAC addresses

VLAN

4K VLANs

Guest VLAN and voice VLAN

GVRP

MUX VLAN

VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports

1:1 and N:1 VLAN Mapping

Reliability

RRPP ring topology and RRPP multi-instance

Smart Link tree topology and Smart Link multi-instance, providing the millisecond-level

protection switchover

SEP

ERPS (G.8032)

BFD for OSPF, BFD for IS-IS, BFD for VRRP, and BFD for PIM

STP(IEEE 802.1d), RSTP(IEEE 802.1w), and MSTP(IEEE 802.1s)

BPDU protection, root protection, and loop protection

E-Trunk

IP routing

Static routing, RIPv1/v2, RIGng, OSPF, OSPFv3, IS-IS, IS-ISv6, BGP, BGP4+, and ECMP

IPv6 features

Neighbor Discovery (ND)

Path MTU (PMTU)

IPv6 ping, IPv6 tracert, and IPv6 Telnet

ACLs based on the source IPv6 address, destination IPv6 address, Layer 4 ports, or protocol

type

MLD v1/v2 snooping

IPv4 and IPv6 dual stack

6to4 tunnel, ISATAP tunnel, and manually configur ed tunnel

Multicast

IGMP v1/v2/v3 snooping and IGMP fast leave

Multicast forwarding in a VLAN and multicast replication between VLANs

Multicast load balancing among member ports of a trunk

Controllable multicast

Port-based multicast traffic statistics

IGMP v1/v2/v3, PIM-SM, PIM-DM, and PIM-SSM

MSDP

QoS/ACL

Rate limiting on packets sent and received by an interface

Packet redirection

Port-based traffic policing and two-rate three-color CAR

Eight queues on each port

WRR, DRR, SP, WRR+SP, and DRR+SP queue scheduling algorithms

WRED (supported by the S5710-EI)

Re-marking of the 802.1p priority and DSCP priority

Packet filtering at Layer 2 to Layer 4, filtering out invalid fr ames based on the source MAC

address, destination MAC address, source IP address, destination IP address, TCP/UDP port

number, protocol type, and VLAN ID

Rate limiting in each queue and traffic shaping on ports

Security

User privilege management and password protection

DoS attack defense, ARP attack defense, and ICMP attack defense

Binding of the IP address, MAC address, interface, and VLAN

Port isolation, port security, and sticky MAC

Blackhole MAC address entries

Limit on the number of learned MAC addresses

802.1x authentication and limit on the number of users on an interface

AAA authentication, RADIUS authentication, HWTACACS+ authentication, and NAC

SSH v2.0

Hypertext Transfer Protocol Secure (HTTPS)

CPU defense

Blacklist and whitelist

Management and maintenance

iStack

MAC Forced Forwarding (MFF)

Virtual cable test

SNMP v1/v2c/v3

RMON

Web NMS

System logs and alarms of different levels

NetStream (supported by S5710-EI)

sFlow

Interoperability

Supports VBST (Compatible with PVST/PVST+/RPVST)

Supports LNP (Similar to DTP)

Supports VCMP (Similar to VTP)

Operating environment

Operating temperature: 0oC–50oC

Relative humidity: 5%–95% (non-condensing)

Input voltage

AC:

Rated voltage range: 100 V to 240 V AC, 50/60 Hz

Maximum voltage range: 90 V to 264 V AC, 50/60 Hz

DC:

Rated voltage range: –48 V to –60 V, DC

Maximum voltage range: –36 V to –72 V, DC

Note: PoE-support switches do not use DC power supplies.

Dimensions(W x D x H)

442 mm x 420 mm x 43.6 mm

Power consumption

Non-PoE model:< 60W

PoE model: < 842W(PoE: 740W)
