MA5811S-AE08
| Model: | MA5811S-AE08 – Huawei SmartAX MA58xx Series |
| Detail: | Huawei SmartAX MA5811S-AE08, supporting GPON/XG-PON/GE/10GE optical port, 8 subscriber LINES (0-7) with the broadband service |
Delivery & Return
We want you to be happy with your purchase and we apologize if it is not. For whatever reason that you are not satisfied, we would be most happy to provide exchanges and returns for all items purchased from us if the following conditions are met.
Rules
For delivery and returns information, please review our Return & Refund Policy or contact our team before ordering. Eligibility and time limits depend on the product condition, order type, manufacturer terms, and the terms agreed in your quotation.
Interpretation and Definitions
For delivery and returns information, please review our Return & Refund Policy or contact our team before ordering. Eligibility and time limits depend on the product condition, order type, manufacturer terms, and the terms agreed in your quotation.
Accessories from hundreds of brands
MA5811S-AE08 Specification | |
Technical Specifications | |
Dimension (H × W × D) | 380 mm × 330 mm × 111 mm |
Operating Environment Temperature | -40°C to +55°C |
Operating Environment Humidity | 5% RH to 95% RH |
Atmospheric Pressure | 70 kPa to 106 kPa |
Altitude | ≤ 4000 m |
Uplink port | GPON/XG-PON/GE/10GE optical port |
G.fast port | It provides 8 subscriber LINES (0-7) with the broadband service. |
Power supply | Reverse power supply: 57 V/0.614 A Maximum power consumption: 24 W Reverse power supply distance: 100 m (0.5-mm cable diameter) |
GPON Optical Module | |
Connector type | SC/UPC |
Port Mode | Single-mode |
Maximum transmission distance | 20Km |
Center wavelength | TX: 1310 nm RX: 1490 nm |
TX optical power (dBm) | 0.5 to 5 |
Maximum RX sensitivity (dBm) | – 27 dBm |
Extinction ratio (dB) | > 10 |
Standard compliance | ITU-T G.984.2/ G.984.5 Class B+ |
Overload optical power | – 8 dBm |
Ambient temperature range | -40°C to +85°C |
