C1-C6816-X-LE Datasheet

Model:C1-C6816-X-LE – Cisco ONE Catalyst 6800 Series Platform
Detail:Cisco ONE Catalyst 6816-X-Chassis (Standard Tables)
Guaranteed safe & secure checkout
Description
Q & A

Warranty: supplied with the Green Code 1-year standard hardware repair warranty. Any manufacturer warranty terms shown in the specifications below are the manufacturer’s own.

While constructing any sort of office, the most fundamental piece of gear you will require is Switch. Likewise, there is just one organization you will hear nowadays that produces a-list switches… and that is Cisco! Cisco produces switches for each area and necessity, from Cisco Switches for both Access and Compact Campus LAN Switches to Cisco Nexus Series switches for server farms.

This 10G/40G-prepared stage is ideal for the individuals who need to present premium 10G administrations in little or moderate size grounds spines. This interesting stage offers 10G port thickness, full IPv4/IPv6, and MPLS/VPLS usefulness with huge table sizes (up to 256,000 FIB sections). With a full set-up of L2/L3, virtualization, security, multicast, IPv6, application permeability, savvy activities, and rich media administrations, the Cisco Catalyst 6840-X conveys exceptional abilities on day one. This stage additionally runs on similar engineering as the Cisco Catalyst 6500 Supervisor Engine 2T and hence offers strength with demonstrated working framework programming.

Main Features:

  • X Chassis (Standard Tables)
  • Switch
  • managed
  • 16 x 1 Gigabit SFP/ 10 Gigabit SFP+
  • desktop
  • rack-mountable

C1-C6816-X-LE Specification

General
Device TypeSwitch – 16 ports – L3 – managed
Enclosure TypeDesktop, rack-mountable 2U
Subtype10 Gigabit Ethernet
Ports16 x 1 Gigabit SFP/ 10 Gigabit SFP+
PerformanceForwarding performance: up to 60 Mpps ¦ Switching capacity (full duplex): up to 180 Mpps ¦ IPv4 routing: up to 60 Mpps ¦ IPv6 routing: up to 30 Mpps ¦ Layer 2 bridging: up to 60 Mpps
CapacityIPv4 routes: 256000 ¦ IPv6 routes: 128000 ¦ NetFlow entries: 512000 ¦ IPv4 routes (Multicast): 128000 ¦ IPv6 routes (Multicast): 64000 ¦ Virtual interfaces (VLANs): 4094 ¦ Domains: 16000 ¦ ACL entries: 64000 ¦ Logical interfaces: 128000
MAC Address Table Size128K entries
Jumbo Frame Support9216 bytes
Routing ProtocolIGMPv2, IGMP, PIM-SM, PIM-DM, IGMPv3, GRE, MSDP, MLDv2, MLD, MPLS, PIM-SMv6, PIM-DMv6
Remote Management ProtocolRMON, SMON
FeaturesNAT support, VLAN support, traffic shaping, DoS attack prevention, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), PIM snooping, Spanning Tree Protocol (STP) support, tunneling, Access Control List (ACL) support, Quality of Service (QoS), Virtual Route Forwarding-Lite (VRF-Lite), reset button, Unicast Reverse Path Forwarding (URPF), IPv4 support, Deficit Weighted Round Robin (DWRR), Shaped Round Robin (SRR), Port Security, Remote Switch Port Analyzer (RSPAN), NetFlow, Management Information Base (MIB), Flexible NetFlow (FNF), Multicast Source Discovery Protocol (MSDP), 802.1x authentication, DiffServ Code Point (DSCP) support, MACsec support, Virtual Private LAN Service (VPLS), Control plane protection (CoPP), Label Distribution Protocol (LDP), Location ID Separation Protocol (LISP), Instant Access (IA), Virtual Switching System (VSS)
Compliant StandardsIEEE 802.1x, IEEE 802.1ae
RAM4 GB
Expansion / Connectivity
Interfaces16 x 10GBase-X SFP+ ¦ 1 x management (LAN) RJ-45 ¦ 1 x serial (console) RJ-45 ¦ 1 x USB Type A ¦ 1 x console (mini-USB) Type B ¦ 1 x management SFP
Power
Power DeviceInternal power supply – hot-plug
Installed Qty0 (installed) / 2 (max)
Power RedundancyOptional
Power Redundancy Scheme1+1 (with optional power supply)
Miscellaneous
Compliant StandardsCISPR 22 Class A, EN55024, EN55022 Class A, EN50082-1, EN 61000-6-1, UL 60950-1 Second Edition, FCC Part 15 A, AS/NZS 3548 Class A, AS/NZS 60950, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, GR-1089-CORE, CAN/CSA C22.2 No. 60950, VCCI Class A, ETS 300 386, ETSI 300 019
Software / System Requirements
Software IncludedCisco IOS Advanced Enterprise Services, Cisco IOS IP Services
OS RequiredCisco IOS 15.2(2)SY
Dimensions & Weight
Width17.4 in
Depth21.5 in
Height3.5 in
Weight22.24 lbs
Manufacturer Warranty
Service & SupportLimited warranty – advance parts replacement – 1 year – response time: 10 days
Environmental Parameters
Min Operating Temperature32 °F
Max Operating Temperature104 °F
Humidity Range Operating5 – 90% (non-condensing)
Min Storage Temperature-4 °F
Max Storage Temperature149 °F
Humidity Range Storage5 – 90% (non-condensing)
