AF901A
| Model: | AF901A – Power Distribution for HPE Server |
| Detail: | HPE Intelligent Modular 3Ph 17.3kVA/60309 30A 5-wire 24A/240V (6) C19/Horizontal NA/JP PDU |
AF901A Specification | |
| General | |
| Device Type | Power distribution unit – rack-mountable |
| Power Device | |
| Input Voltage Range | AC 385 – 415 V |
| Frequency Required | 60 Hz |
| Input Connectors | Power IEC 60309 30A |
| Power Output Connectors Details | 6 x power IEC 60320 C19 |
| Max Electric Current | 24 A |
| Power Capacity | 17250 VA |
| Circuit Protection | Circuit breaker |
| Miscellaneous | |
| Included Accessories | Cable ties, cable retention brackets |
| Cables Included | Power cable – 12 ft |
| Rack Mounting Kit | Included |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 10 – 90% |
| Dimensions & Weight | |
| Width | 17.5 in |
| Depth | 7.6 in |
| Height | 1.6 in |
| Weight | 20.06 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 21.5 in |
| Shipping Depth | 15 in |
| Shipping Height | 12.2 in |
| Shipping Weight | 22.3 lbs |
| Compatibility Information | |
| Designed For | HPE 600mm x 1075mm Advanced Pallet Rack, 600mm x 1075mm Advanced Shock Rack, 600mm x 1075mm Enterprise Crate Rack, 600mm x 1075mm Enterprise Pallet Rack, 600mm x 1075mm Enterprise Shock Rack, 600mm x 1200mm Advanced Pallet Rack, 600mm x 1200mm Advanced Shock Rack, 600mm x 1200mm Enterprise Air Duct Rack, 600mm x 1200mm Enterprise Pallet Rack, 600mm x 1200mm Enterprise Shock Network Rack, 600mm x 1200mm Enterprise Shock Rack, 600mm x 1200mm Grey Enterprise Air Duct Rack, 600mm x 1200mm Grey Enterprise Shock Rack, 600mm x 1200mm Network Advanced Shock Rack, 800mm x 1075mm Enterprise Pallet Rack, 800mm x 1075mm Enterprise Shock Rack, 800mm x 1200mm Advanced Pallet Rack, 800mm x 1200mm Advanced Shock Rack, 800mm x 1200mm Enterprise Pallet Rack, 800mm x 1200mm Enterprise Shock Network Rack, 800mm x 1200mm Enterprise Shock Rack, 800mm x 1200mm Grey Enterprise Shock Network Rack, 800mm x 1200mm Grey Enterprise Shock Rack, 800mm x 1200mm Network Advanced Shock Rack ¦ HPE 11000 G2 Series 11642 1075mm Pallet Universal Rack ¦ HPE Advanced Series Racks 42U 600mm x 1075mm Kitted Advanced Pallet Rack with Side Panels and Baying, 42U 600mm x 1075mm Kitted Advanced Shock Rack with Side Panels and Baying ¦ HPE ProLiant DL120 Gen9, DL120 Gen9 Entry, DL160 Gen8, DL160 Gen8 Base, DL160 Gen8 Entry, DL160 Gen8 Performance, DL160 Gen9, DL160 Gen9 Base, DL160 Gen9 Entry, DL160 Gen9 Performance, DL165 G7 Base, DL165 G7 Entry, DL165 G7 Performance, DL180 Gen9, DL180 Gen9 Base, DL180 Gen9 Entry, DL180 Gen9 Storage, DL20 Gen9, DL20 Gen9 Entry, DL20 Gen9 Performance, DL360 G7 Special Server, DL380 G7 Special Server, DL380 Gen9, DL380 Gen9 Base, DL380 Gen9 Entry, DL380 Gen9 High Performance, DL380 Gen9 Performance, DL580 Gen8, DL580 Gen8 Base, DL580 Gen8 High Performance, DL60 Gen9, DL60 Gen9 Base, DL60 Gen9 Entry, DL80 Gen9, DL80 Gen9 Base, DL80 Gen9 Entry, ML150 Gen9, ML150 Gen9 Base, ML150 Gen9 Entry, ML150 Gen9 Performance, SL160s G6 |
