AF460A
| Model: | AF460A – Uninterruptible Power System for HPE Server |
| Detail: | HPE R5000 3U L630 High Voltage NA/JP Uninterruptible Power System |
AF460A Specification | |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 191.8 lbs |
| Shipping Depth | 38.8 in |
| Shipping Height | 14.4 in |
| Shipping Width | 23.6 in |
| General | |
| Product Type | UPS |
| Subcategory | UPS |
| Run Time Details | |
| Run Time (Up To) | 5.7 |
| Load Type | Full load |
| UPS | |
| Expandable Battery | Expandable |
| Battery Technology | Lead acid |
| Battery | |
| Recharge Time | 48 hours |
| Run Time (Up To) | 5.7 min |
| Load Type | At full load |
| Power Output Connectors Details | |
| Connector Type | Power NEMA L6-30 |
| Connector Qty | 1 |
| Cable | |
| Connectivity Details Type | Power cable |
| Connectivity Details Length | 10 ft |
| Environmental Parameters | |
| Sound Emission | 45 dB |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 – 80% (non-condensing) |
| Header | |
| Compatibility | PC |
| Country Kits | Japan, North America |
| Manufacturer | Hewlett-Packard |
| Packaged Quantity | 1 |
| Product Line | HPE UPS |
| Model | R5000 |
| Brand | HPE |
| Miscellaneous | |
| Rack Mounting Kit | Included |
| Compliant Standards | BSMI, C-Tick, CSA C22.2, EN 50091-1, EN 50091-2, EN 60950-1, FCC CFR47 Part 15, FCC Class A certified, GOST, GS, IEC 62040-1-1, UL 1778, UL 60950-1 |
| Equipment Protection Value | 250000 US Dollars |
| Height (Rack Units) | 3 |
| Power Device | |
| Voltage Required | AC 220/230/240 V |
| Frequency Required | 50/60 Hz |
| Power Provided | 4.5 kW |
| Input Connector Type | Power NEMA L6-30 |
| Input Connector Qty | 1 |
| Output Connector Qty | 9 |
| Voltage Provided Margin | + 6% / – 10% |
| UPS Output Waveform | Sinewave |
| Form Factor | Rack-mountable |
| Power Capacity (VA) | 5000 VA |
| Software | |
| Type | Drivers & Utilities |
| Dimensions & Weight | |
| Width | 17.2 in |
| Depth | 29.3 in |
| Height | 5 in |
| Weight | 125.66 lbs |
